Precision engineering

Enabling free movement in two planes at the same time, the ball-pin is a critical component. That’s why our ball-pins are manufactured from high-grade steel and machined to micron tolerances. Together with a polyoxymethylene nylon ball-pin seat, they provide optimum durability and smooth joint operation.

Extensive testing

Delphi ball joints undergo rigorous performance tests including angular stress testing, where the ball is rotated through its angular and rotational travel under load, as well as a pull and push out test, to measure the force required for it to break away from the housing. These important safety tests ensure the ball joint can withstand the same forces as the OE part.

Longer service intervals

We provide a range of sealed ball joints, that are lubed for life with a high-specification grease, to minimise maintenance requirements. Alongside our precision ball-pin finish and improved rubber boot design, they offer longer ball joint service intervals and better grease retention.

Greater protection

To help prevent damage to the joint’s internal components, all our ball joints come with a special chloroprene rubber cover. The new and improved formula maintains its durability even in extreme temperatures, providing added protection from road dirt or salt and allowing continued free movement of the ball joint for a longer lasting part.

Three-year warranty – available in UK

As a guarantee of our OE-quality standards, we offer a three-year or 36,000-mile warranty on all our ball joints. So, you can fit Delphi steering parts with complete confidence.

Cataphoretic coating

Like many of our steering parts, Delphi ball joints feature an environmentally friendly cataphoretic coating for tougher and longer lasting protection from corrosion caused by salt, dirt and water and other contaminants.

Tech Tip

Delphi is advising technicians to help ensure a quality steering and suspension repair by replacing the entire ball joint component where the rubber boot is split, cracked, damaged or missing. In these instances, there is a high probability that damage to the ball joint may have occurred, indicating the joint is likely to fail even after the boot cover has been replaced. Replacing the entire ball joint component can help avoid potential premature failure, which can be safety-critical and costly.

By replacing the boot only and not the complete ball joint unit, the rubber boot could potentially seal in the damaging substances the joint has been exposed to, resulting in accelerated rust and corrosive damage to the joint. In addition, the ball joint is designed to operate with a grease lubricant.

A defective boot could lead to a loss of this essential lubrication, as it may be washed away with water, dry out or become coated with dirt and other debris.

The Delphi Difference

100 years of OE experience, supplier to the world’s top automakers
OE heritage and knowledge built into every aftermarket part
Comprehensive portfolio for a wide range of vehicles and model years
Streamlined SKUs for easy inventory management
Support through tools, tips and training

Related product resources and downloads

Steering & Suspension 5 min read

How to replace a press-in ball joint

Share Resource:

Steering & Suspension How to Technicians 5 min read

Resource Highlights

In this article you will find a step-by-step guide to replace a press-in ball joint.

Suspect a possible bad ball joint? Then you’re serving your customer well by being proactive about the repair for such a safety-critical part. Replacing a ball joint won’t be the same process for every vehicle, especially since there are several different kinds of ball joints. In the video below, we’ll take a look at how to replace a press-in ball joint. Specifically, we’re looking at a Honda Civic, which Delphi covers with our part TC1299.

We’ll explain the full process below the video as well.

How can I tell if my customer’s car has a bad ball joint?

We recommend a thorough pre-alignment inspection. Some common signs include:

Unusual noises
Instability
Handling concerns

What should I look for when inspecting a ball joint?

Keep in mind that integrity of the rubber boot is the key. A common problem is that the boot will split, grease will leak out, and cause problems. Generally when inspecting a ball joint, we look for movement outside of manufacturers’ specifications, but with low friction non greaseable joints you should look for seized joints that show no movement.

What tools will I need for a press-in ball joint replacement?

Ball joint press kit (including C-clamp and adapters)
Socket, ratchet, torque, and extension wrenches
Socket air tools
Ball joint separator (also known as a pickle fork)
Needle nose pliers
Screwdrivers
Tire iron
Side cutters
Axle press
Hammer
Shop towels
Rust penetrant

Steps to replace a press-in ball joint

Make sure you follow manufacturers’ recommendations for installation, torque specs, and TSBs where applicable.

Removing the ball joint

Use side cutters to remove the cotter pin that’s securing the fastening nut.
Use a socket wrench to remove the fastening nut.
Use a socket wrench to remove the axle nut.
Push the axle back through and loosen the knuckle assembly, moving it to gain access to the ball joint.
Separate the ball joint from the lower control arm with your ball joint separator. You can operate the tool with a socket wrench, using an appropriately sized socket. You will hear a crisp, clear snap when the stud pops loose from the lower control arm.
Push the axle shaft back through the hub assembly. You may need to use an axle press and a socket wrench to get things started because often the axle can become dry or stuck over time. Make sure you can swing the axle shaft clear and prop it up (perhaps with a piece of wood or a tool). This frees up the lower ball joint.
Push the outer CV joint back through the hub assembly to loosen it up, but make sure you don’t pull the inner CV joint out of the transmission. You only want to remove the knuckle and assembly.
Remove the axle press with the socket wrench.
Remove the knuckle and the strut assembly out so your press can access the ball joint.
Remove the rubber boot by knocking it off with a hammer and screwdriver. The new ball joint comes with a new boot so you don’t have to worry about protecting the old one. Clean off the exposed ball joint stud with a shop rag.
Set up your ball joint press. The adapters you’ll need to use are vehicle-specific. The upper and lower cone will fit together on top and bottom of the ball joint.
Run the press inwards to press out the old ball joint with the socket wrench and ball joint press.
Remove the top and bottom accessories and remove the old ball joint. If it comes out cleanly with the press, just double check that there are no edges to be concerned about on the steering knuckle, and no hidden damage.

Set up ball joint separator tool.	Remove axle nut.
Fit upper adapter onto ball joint.	Fit lower adapter onto ball joint.

Replacing the ball joint

It’s a good rule of thumb to always check the new and old components side by side to make sure your new part matches the one coming out. Take off the new retaining nut and plastic shipping cover.
Insert the new ball joint into the knuckle and make sure it’s level.
The adapters to install the ball joint are different from the ones you used to remove the old one. A small specially designed adapter fits tightly over the upper portion of the ball joint. Fit this on, and place the press on top of the upper adapter.
The lower adapter fits over the large ball joint screw under the ball joint, with room for the stud and threads so that they won’t get damaged during the installation process.
Make sure everything is square and true to the knuckle, and wind the press up to tighten it by hand. It’s very important to press the joint in in a level and square manner, with the joint centered and aligned to the knuckle. Wiggle while tightening to make sure everything remains straight.
Once you are sure you have clearance and everything is safe and secure, use a socket wrench to finish pressing in the ball joint with the press.
Once the upper mating surface of the joint meets securely with the knuckle, you can remove the press. Make sure that the rubber boot hasn’t been nicked or touched, and that the threads remain safe and undamaged. Check that the ball joint has pressed fully down.
Begin working the axle shaft back into the wheel bearing. Apply a bit of rust penetrant to help it slide back in properly. Match the splines into the hub.
Re-secure the knuckle and the new ball joint stud to the lower control arm. Make sure the axle is feeding through properly and starting to poke through the outside of the hub assembly.
Add the securing nut and tighten with a socket wrench.
Add the cotter pin.
Reinstall the axle nut and torque it to manufacturer specifications. If it’s not all the way through, you can grab the outside CV joint to help you.
Finally, you can safely lower the vehicle to the ground. Finish up the job by taking the vehicle to get an alignment.

Now you’ve done it! A safe and successful press-in ball joint replacement.

Wind up press.	Joint released from knuckle.
Wind up ball joint press.	Resecure ball joint stud to control arm.

Do I need a retaining clip?

For this unit TC1299 there is no need for a retaining clip (or snap ring). There was no retaining clip in the OE unit and the Delphi OE design is exactly the same, so a clip is not necessary. The new part comes with a cotter pin and the nut for a complete installation.

How many times can I replace a ball joint on the same vehicle?

Follow manufacturer recommendations. For this part, TC1299, only one replacement opportunity is possible per the OE. If the joint needs to be replaced again, the OE recommends purchasing a new knuckle and ball joint, and replacing both.

A few safety tips:

It’s important to use a proper ball joint press. In the past, ball joints could be punched or hammered out, but this is no longer best practice.
Make sure you have room to work. The ball joint press needs a certain amount of space, so it’s preferable to use a hoist. If you’re working on the ground with axle stands, make sure you have enough clearance on the ground.
